I love vintage sewing machines. Their all metal construction, brilliant engineering, and retro lines make me swoon. I wish I could bring home every vintage machine I come across, but I’m pretty much at capacity over here. So I’ve tried to be selective and hold out for the perfect vintage zigzag machine. And that is why I pretty much imploded when I came across a craigslist ad for this beauty — my dream vintage zigzag machine, a Brother Super Select-o-matic or Brother HZ3B3 Model 100. It took a week to coordinate the sale, but it was so worth it. Restoring it took a couple of weeks, but I’m so in love with her now that she’s finished!
Before picture from the Craigslist ad. Such a dirty girl <3
The seller was an absolutely lovely woman. If we had had more time I could have spent hours talking to her! She explained that the machine had belonged to her late mother in law and hadn’t been used in years and years. Another fun fact? This beast is H-E-A-V-Y. In its solid 8 drawer cabinet, the machine easily weighs over 100 pounds. I’m sure my husband and I were quite the picture maneuvering this behemoth out of a second floor bedroom, but we succeeded.
Action shot: cabinet restoration
I spent two weeks restoring the cabinet, which was definitely showing its age. It took over a dozen coats of Tung Oil and a lot of elbow grease, but it looks a million times better. It is still a little weathered looking, but I love it. It’s the perfect vintage piece to ground an otherwise bright space.
The machine itself was really very clean inside, but the outside? Not so much. There was a lot of odd yellow staining. And.it.was.stubbon. Given its age, I assume that it was nicotine staining? I used a lot of Qtips and barkeeper’s friend to remove the stains and polish the chrome. Unfortunately, I took off a little paint getting rid of the staining. I feel pretty badly about that, but I couldn’t leave it as it was either.
Originally, it had been wired with a knee control, but the lever was very squeaky and the cords felt brittle. So, I picked up a new cord block and switched over to a shiny new foot peddle. Once the machine was thoroughly cleaned I oiled it well — it’s been purring like a kitten ever since.
This machine is seriously fun stuff. It looks like an old vintage car with its powder blue paint job and shiny chrome knobs. But what really puts it over the top is the red “Switch Over Knob” which spins as it does the embroidery stitches. Totally gratuitous and squeal worthy! I’m adding a video because it really is too cool not to share.
But she isn’t all looks, no, no. This baby sports a 1.2 amp motor — that’s twice as strong as my Janome Horizon. When you put the pedal to the metal, there is a slight but noticeable breeze — it seriously feels like it might take off and I love it! It goes through leather, vinyl, and canvas like butter. She uses a standard class 15 bobbin, so finding replacement parts (if I ever need them!) will be easy. I also love the way her gib pops open with a “snap-out race hook,” no screwdriver needed. It makes removing stray threads a snap (literally!), instead of a nightmare (ahem, I’m looking at you little Featherweight). I can’t wait to make bags on her! Or you know, maybe sailboat sails. Just because I can.
Linking up with Finish it Up Friday!
Genius engineering at work: Snap out race hook on the Brother Super Select-o-matic
As a PSA, I’m going to include some more nitty gritty info about this machine. There is very little info about this model on the internet, and I couldn’t find a manual anywhere online. The manufacturer didn’t even have a manual for this model, though they did provide a manual for an earlier model. So, feel free to stop reading here, though you’re welcome to dork out with me below 🙂
This machine is a “Brother Super Select-O-Matic” aka “Brother HZ3B3 Model 100,” and was manufactured by Brother in Japan, likely in the 1960s. An earlier version of this machine, “the Select-o-Matic” had a differently shaped Stitch Width Window which was located further to the left. A later version, the “Brother 210” is also similar, but replaced the Stitch Regulator with a reverse button, did away with the separate Stitch Selector Knob, and flipped the bobbin on to the horizontal axis. There is a great blog post about the 210 (and related machines) by Brooke at Custom Style here.
Like other Japanese made machines of the time, these machines were sold as badged machines in the US. That is, the seller’s brand was added on top of or in addition to “Brother” once the machines arrived stateside. As a result, this machine and other “Select-o-matic” models were sold under dozens of brands including Atlas, Wizard, and Coronado just to name a few. Crazy, huh?
As you might imagine, badged machines are notoriously difficult to track. They all have different model names, and even the manufacturer didn’t keep track of serial numbers or production years. I was very fortunate to find the original manual and warranty card in one of the cabinet drawers. I am uploading a copy of the manual (here: Brother Super Select-o-Matic Manual) and created a little diagram below to help explain how this machine works. I also found a Ruffler in the accessories box, complete with instructions. Here’s a copy of the instructions for that, too: Brother Ruffler Attachment – Manual.
The machine has three modes: automatic zigzag, semi-automatic, and manual zigzag. The modes are accessed by manipulating the Switch Over Knob (Pull out for automatic and semi-automatic zigzagging, push in for manual zigzagging). The automatic mode is very familiar for modern sewists. In automatic mode you select your settings, and then the machine sews a given stitch (straight or zigzag). But the semi-automatic and manual modes? Whoa, baby. In those modes, the user *manually* swings the Needle Position Knob from left to right in timing with the Stitch Width Window to produce custom embroidery stitches. No, I’m not kidding you. It’s insane. To quote the manual in all of its vintage glory:
“The variety of zig-zag designs that can be made on this machine by simple manual manipulation is unlimited. It depends entirely on the creative ability of the operator and the skill acquired in timing the movement of [the Switch Over Knob] with the stitch width.”
Well, thank you 1960s for the condescension. I’m not ashamed to admit that this operator has not acquired this skill. I’m seriously awful at it. Haha 🙂
Alright, that’s all the info I have. If you read this far thank you for indulging me and my dork-out session!
